Waltham Watch Mainsprings

Just click order and in either the order instuction box, or the order comments box enter the serial number found stamped on the watch movement. We will then look up the serial number and send you the right mainspring.

WALTHAM-MS-SS#
$50.00
Now on Sale $45.00!


Size 18, 1877 and 1879 Models factory mainspring # 2203, width in mm 2.9, strength in mm 0.225, length inches 21, end T For 18 size Waltham Model 1857 use this spring JA-701 which is strength Dennison 1 1/2 or Waltham Spring JA-703 Strength 2 1/2 (0.215 mm). Another option is the Illinois Spring JA-404, which is also a T End, Dennison strength 2 (0.22 mm). The no longer made 1857 springs were listed as 23 inches long with strength 0.22 mm and height/width 2.90 mm.

JA-701



Watham Size 18, 1877 and 1879 Models factory mainspring # 2203, width in mm 2.9, strength in mm 0.215, length inches 21, end T For 18 size Waltham Model 1857 use this White Alloy Mainspring JA-703 Dennison Strength 2 1/2 (0.215 mm). Another option is the Illinois Spring JA-404, which is also a T End, Dennison strength 2 (0.22 mm). The no longer made 1857 No. 2200 Old Style and No. 2202 1857 New Style springs were listed as 20 inches long strength 0.20 and width 2.80, and 23 inches long with strength 0.22 mm and height/width 2.90 mm.

JA-703




Size 18, 1892 model factory mainspring # 2222, width in mm 3.3, strength in mm 0.16, length inches 25, end HOLE

JA-704



Size 18, 1883 model factory mainspring # 2205, width in mm 3, strength in mm 0.22, length inches 21, end T

JA-705



Size 16, 1899 and 1908 models factory mainspring # 2227/2267, width in mm 2.8, strength in mm 0.18, length inches 25, end HOLE.

JA-710



Size 16, 1888 model factory mainspring numbers 2218 and 2267, width in mm 2.8, strength in mm 0.19, length inches 25, end HOLE

JA-713



Size 16, Running Barrel Model 1945 factory mainspring numbers 2247 and 2268, width in mm 2.6, strength in mm 0.17, length inches 19-1/2, end D.B. & HOLE

JA-715



Fit 14 size and 10 size Colonial A model, factory mainspring number 2234, width in mm 1.3, strength in mm 0.175, length inches 19, end HOLE

JA-717



Size 14 Running Barrel Colonial R Model, factory numbers 2252 and 2269, width in mm 1.62, strength in mm 0.17, length inches 19, end HOLE

JA-718



For Waltham 12 Size 1894 model and Waltham 14 size 1897 model replaces factory mainsprings #"s 2224A and 2279. The width in mm is 2.15, strength (thickness) in mm 0.16, length inches 19-1/4, Hole end.

JA-720



For 14 and 16 Size, factory # 47334, thin barrel .150". Spring width in mm is 2.5, strength in mm 0.21, length in inches is 20, with end T Also this is the replacement mainspring for the Waltham 14 size 2211 mainspring. Swiss Made White Alloy Mainspring

JA-421



Size 6 and 8 size 1873 model, factory mainspring # 2215, width in mm 1.9, strength in mm 0.21, length inches 16, end T

JA-725 , no longer available. Use JA-726



Size 0, 1891 model factory mainspring # 2220, width in mm 1.5, strength in mm 0.15, length inches 16, end HOLE

JA-729



Size 0 and 3/0 size 1900 model, factory mainspring # 2228, width in mm 1.7, strength in mm 0.13, length inches 15, end HOLE

JA-731



Size 0, and 3/0 size 1907 model, factory mainspring numbers 2230/2228 and 2278, width in mm 2.05, strength in mm 0.14, length inches 15, end HOLE

JA-732



Size 0, and 3/0 size 1907 model, factory mainspring numbers 2230/2228 and 2278, width in mm 2.05, strength in mm 0.13, length inches 15, end HOLE

JA-733



Size 6/0 Hunting case model 1898 and 6/0 1945 model factory mainspring numbers 2226 and 2276, width in mm 1.5, strength in mm 0.12, length inches 13-1/2, end HOLE

JA-735
$39.00


Size 6/0, Open Face 1912 model factory mainspring # 2235, width in mm 1.3, strength in mm 0.13, length inches 13-1/2, end HOLE

JA-737



Size 6/0 Hunting case model 1898 and 6/0 1945 model factory mainspring numbers 2226 and 2276, width in mm 1.5, strength in mm 0.12, length inches 9.5, end HOLE

JA-738



Size 7-1/4 Ligne Rectangular, factory mainspring numbers 2238 and 2274, width in mm 1.3, strength in mm 0.11, length inches 12, end D.B. & HOLE

JA-746



Size 6-1/2 L, factory # 2239/2272, width in mm 1.05, strength in mm 0.1, length inches 9.75, end HOLE

JA-748



Size 7-1/2 L, factory # 2234/2266, width in mm 1.12, strength in mm 0.1, length inches 13, end HOLE

JA-756



Size 6-3/4 L, factory # 2244/2261, width in mm 1.2, strength in mm 0.065, length inches 7.75, end HOLE

JA-758



Size 16, Running Barrel Timer 11609 factory mainspring # 2246, width in mm 1.5, strength in mm 0.165, length inches 17, end D.B.-T

JA-759



Size 6/0, factory # 2248/2265, width in mm 1.5, strength in mm 0.1, length inches 12, end D.B. & HOLE

JA-760



Size 6-3/4 & 7L-675, factory # 2249/2263, width in mm 1.15, strength in mm 0.065, length inches 7.5, end TONGUE

JA-762



Size 6-3/4 & 8L-678, factory # 2251/2262, width in mm 1.3, strength in mm 0.08, length inches 9.5, end D.B. & HOLE

JA-763



Size 8-3/4L-870, factory # 2253, width in mm 1.3, strength in mm 0.085, length inches 9, end D.B. & HOLE

JA-764



Size 22, Waltham Aircraft Clock Type A-11 Models 22809 and 22811, Travel and Desk Clock Model 22809-P. The factory number for the Pioneer Resilient mainspring is 2245 and for the Waltham Permaforce Alloy mainspring 2275. The width in mm is 5.4, strength in mm 0.22, length inches 25, end D.B.-T For the A13A clock

JA-767



Size 6/0, factory # 2248/2265, width in mm 1.5, strength in mm 0.11, length inches 12, end D.B. & HOLE

JA-761
